7903-9Q-81CP

Sprayer W/Hose


The water ladle is a washing appliance from ancient time till modern day life. JUSTIME Team has integrated the water ladle image with the design concept to reproduce the tradition, regenerating the old spirit. We hope users will associate this Toilet Spray with traditional culture and life style. JUSTIME sincerely hopes the design will be popular among everyone- reminding adults of the past about the original charming and also making kids experience the beauty of traditional and modern times.


Color: Polished Chrome

  • Polished Chrome
  • White (coating)

Share


1.Users could control the Spray with only one finger, one press to open water and the other press to close it, easily and conveniently.
2.The optional check valve and flow restrictor could be added into the sprayer.
3.The sprayer can stand the presure from 0.5 to 5 kg/cm^2
4.Shower hose with SANTOPRENE tube (meets NSF approval), can stand15Kg/cm2 water pressure and 120℃ heat.
5.Brass with Chrome plated meets ASTM-SC2 standard.
6.Tube material meets JIS C2700 Standard.
7.Forging body material meets JIS 3771 Standard.


Download

7903-9Q-81CW Installation

7903-9Q-81CP SketchUp

7903-9Q-81CW SketchUp
