6904-XZ-80CP
Concealed Valve W/Diverter & Check Valve W/ Inlet Stop Version(4~6 kg/cm^2)
In the East, dragon represents honor and auspicious meaning. It refers to the spirit of this product design. Designed main body style as square shape, the aesthetics of symmetry exudes a stylish and charming atmosphere. With R angle processed, it softens the sharp angle of hard steel, and brings soft and elegant atmosphere to a bathroom space.
Color: Polished Chrome
Share
Download
1.Brass forging handle meets JIS 3771 standard.
2.Material of faceplate is stainless steel SUS 304.
3.The body of valve should be concealed in the wall beforehand with 1"(2.5cm) adjusting space.
4.The check valves are assembled in both left and right sides water inlets to prevent the water from flowing back.
5.The applicable water pressure is from 4 to 6 Kg/cm^2. Use the C-ring provided if the water pressure is under 1Kg/cm2(14.2PSI)
6.With inlet stop valve, provide convenience for maintenance.
7.Thread of water supply wall outlet fits for G 1/2, R 1/2, 1/2 PT, 1/2 NPSM and 1/2 NPT.
8.Coordinates with other products in Dragon collection.
6904-XZ-80CP SketchUp
6904-XZ-80CP CAD
