6757-91-80CP
Basin Faucet
This series is a typical cylindrical body design, which shows a balanced and symmetrical beauty. The simple shape of the handle, shows the generous and tidy on the appearance. Overall mix to create a noble, harmonious visual experience.
Color: Polished Chrome
Share
Download
1.Ceramic valve with CERAMTEC ceramic disc / (Germany)
2.Stainless steel braided hose with M10 × 1.0mm (Male thread connect to faucet body) and 1/2"-14NPSM (Female thread connect to water supplier system).
3.Handle can be moved up to 25° to adjust water flow from closed position, hot and cold water controlled by swinging handle for 45° both right and left sides.
4.Stainless steel braided hose with SANTOPRENE tube (meets NSF approval), can be stood 15Kg/cm2 water pressure and 120℃ heat.
5.Aerator with removable flow restrictor (2.2 GPM max.), end-user can take off it for larger water flow if necessary.
6.Brass with Chrome plated, meet ASTM-SC2 standard.
Authorization Code
6757-91-80CP SketchUp
6757-91-80CP CAD
