6780-94-81CP

Bath/Shower Mixer


Utilizing the simplify concept of Tai Chi motion, creating extraordinary look on the Tai Chi Series faucets. Featuring the Tai Chi notion of "soft against hard" through its soft cut of the faucet body and flow of water. Adding into faucet, the "Yin and Yang" aspect of Tai Chi, creating two types of faucets, the femininity and masculinity.


Color: Polished Chrome

  • CP

Share

Download

6780-94-81CP Overview

6780-94-81CP Specification

6780-94-81CP Installation


1.Ceramic valve with CERAMTEC ceramic disc / (Germany)
2.Handle can be moved up to 25° to adjust water flow from closed position, hot and cold water controlled by swinging handle for 45° both right and left sides.
3.The available distance between two centers of wall water-outlet is 122mm to 178mm.
4.Elastic shower hose can be extended from 1.5 meter to 2 meter and stand 15Kg/cm2 water pressure.
5.Rotate and remove the shower spray head for clearing if necessary.
6.Adjustable angle of the hand-shower bracket.
7.With R 1/2 to water supply wall outlet。
8.Casting material meets ISO CuZn40Pb Standard
9.Handle material meets JIS 3771 Standard
10.Brass with Chrome plated meets ASTM-SC2 standard.
