6780-99-81CP

Bidet Mixer


Utilizing the simplify concept of Tai Chi motion, creating extraordinary look on the Tai Chi Series faucets. Featuring the Tai Chi notion of "soft against hard" through its soft cut of the faucet body and flow of water. Adding into faucet, the "Yin and Yang" aspect of Tai Chi, creating two types of faucets, the femininity and masculinity.


Color: Polished Chrome

  • CP

Share

Download

6780-99-81CP Overview

6780-99-81CP Specification

6780-99-81CP Installation


1.Ceramic valve with CERAMTEC ceramic disc / (Germany)
2.Handle can be moved up to 22° to adjust water flow from closed position; hot and cold water controlled by swinging handle for 45° both right and left sides.
3.Stainless steel braided hose with M10 x 1.0mm (Male thread connect to faucet body) and 1/2"-14NPSM (Female thread connect to water supply system).
4.Stainless steel braided hose with SANTOPRENE tube (meets NSF approval), can be stood 15Kg/cm2 water pressure and 120℃ heat.
5.Aerator with removable flow restrictor (2.2 GPM max.), end-user can take off it for larger water flow if necessary.
6.Aerator with pivot joint for swiveling 360° and tilting 32°.
7.Casting material meets ISO CuZn40Pb Standard
8.Handle material meets JIS 3771 Standard
9.Brass with Chrome plated meets ASTM-SC2 standard; 5 years guarantee.
10.Regularly cleaning the aerator in case affecting the flow.


Authorization Code

6780-99-81CP SketchUp

6780-99-81CP CAD
