6781-XY-80CP

Concealed Valve W/Diverter & Check Valve W/ Inlet Stop Version(1~4 kg/cm^2)


Overall concept of ETHER Series Faucet is based on the idea of illimitable space outside of sky, and it has also been mentioned by philosophers of Greek and China Taoism. The smooth lines and dim imagine are like aurora on ether and current in deep ocean. The unique design of ETHER breaks so-called shape and brings faucet to artistic decoration level.


Color: Polished Chrome

  • CP

Share

Download

6781-XY-80CP Specification

6781-XY-80CP Installation


1.The electrodeposited coatings have meet SC2 standard of ASTM. Products would have superior antioxidant abilities, long-term durability, and bright surfaces.
2.G1/2 inlet.
3.With replaceable check valve both behind hot and cold water 1/2" inlet. The valve can prevent counterflow, and make a high-level safety.
4.The faucet should be used at the water presure from 1 to 4 kg/cm^2.
5.Handle can be moved up to 25° to adjust water flow rate from closed position, hot and cold water controlled by swinging handle for 45° both right and left sides.
6.The burying depth of embedded body is between 2"(6cm)Min~3"(7.6cm)Max from the finished wall.



Authorization Code

6781-XY-80CP SketchUp
