6790-N2-81CP
Tip-Touch Basin Mixer W/Lift Rod
The design of Arch Series combines well-executed lines and smooth curves to come into the sharply contrastive but perfect visional impression to reveal beauty of mordent fashion and historical culture.
Color: Polished Chrome
Share
Download
1.Universal mold design which uses common parts and increase more convenient for maintained.
2.Pressing the tip-touch aerator to control water flow.
3.The temperature could be adjusted by swinging the handle 45°
4.The inlet of both sides are assembled the check valves for avoiding the backflow of cold and hot water.
6.Tip-touch aerator passes up to 200,000 times on-off life test. (Saving water, no handle valve and electric system).
7.The faucet can stand the presure from 0.5 to 5 kg/cm^2
8.Stainless steel braided hose with M10 x 1.0mm (Male thread connect to faucet body) and 1/2"-14NPSM (Female thread connect to water supply system).
9.Stainless steel braided hose with SANTOPRENE tube (meets NSF approval), can be stood 15Kg/cm2 water pressure and 120℃ heat.
10.Casting material meets ISO CuZn40Pb Standard
11.Material is Brass with Chrome plated and meets ASTM-SC2 standard.
6790-N2-81CP SketchUp
